100N - Universal Gas Struts Springs 150-1000MM Multi Purpose - Ball, Eyelet, Ball Joint

100N - Universal Gas Struts Springs 150-1000MM Multi Purpose - Ball, Eyelet, Ball Joint

Product Overview:
Our high-quality Autorce Universal Gas Struts Absorbers are engineered for a variety of industrial applications. Featuring ball joint or eyelet heads, these gas struts provide excellent durability and efficient load absorption. Designed to reduce vibrations and ensure smooth operation in diverse environments, they are the perfect solution for your load management needs.

Key Specifications:

• Open Length: 150 mm to 1000 mm

• Stroke Length: 35 mm to 445 mm

• Open Length Cap Options: Ø18 mm, Ø21 mm, Ø27 mm

• Stroke Cap Options: Ø8 mm, Ø10 mm, Ø14 mm

• Force Range: 100N to 2000N (model-dependent)

Note:

• On average, 100N lifts approximately 10 kg.

• Example: For a 60 kg load, a 600N model is recommended.

  • If using one gas strut, select 600N.

  • For two gas struts, choose 300N each.

Ball Joint Heads Details:

M6 Ball Joint Heads

• Compatible Diameter: Ø8 / Ø18

• Open Length Range: 150 mm - 750 mm

• Force Range: 100N - 800N

M8 Ball Joint Heads (S Version)

• Compatible Diameter: Ø10 / Ø21

• Open Length Range: 800 mm - 1000 mm

• Force Range: 100N - 800N

M8 Ball Joint Heads (B Version)

• Compatible Diameter: Ø10 / Ø21

• Open Length Range: 200 mm - 1000 mm

• Force Range: 1000N - 1250N

M10 Ball Joint Heads

• Compatible Diameter: Ø14 / Ø27

• Open Length Range: 200 mm - 1000 mm

• Force Range: 1500N - 2000N

Eyelet Heads Details:

M6 Eyelet Heads

• Compatible Diameter: Ø8 / Ø18

• Open Length Range: 150 mm - 750 mm

• Force Range: 100N - 800N

M8 Eyelet Heads

• Compatible Diameter: Ø10 / Ø21

• Open Length Range: 200 mm - 1000 mm

• Force Range: 100N - 1250N

M10 Eyelet Heads

• Compatible Diameter: Ø14 / Ø27

• Open Length Range: 200 mm - 1000 mm

• Force Range: 1500N - 2000N

Available Variants by Open Length and Stroke:

Ø18 mm Cap:

• 150 mm Open Length / 35 mm Stroke (100-700N)

• 200 mm Open Length / 60 mm Stroke (100-800N)

• 250 mm Open Length / 85 mm Stroke (100-800N)

• 300 mm Open Length / 110 mm Stroke (100-800N)

• 350 mm Open Length / 135 mm Stroke (100-800N)

• 400 mm Open Length / 150 mm Stroke (100-800N)

• 450 mm Open Length / 185 mm Stroke (100-800N)

• 500 mm Open Length / 210 mm Stroke (100-800N)

• 550 mm Open Length / 235 mm Stroke (100-800N)

• 600 mm Open Length / 260 mm Stroke (100-800N)

• 650 mm Open Length / 285 mm Stroke (100-800N)

• 700 mm Open Length / 300 mm Stroke (100-800N)

• 750 mm Open Length / 325 mm Stroke (100-800N)

Ø21 mm Cap:

• 150 mm Open Length / 35 mm Stroke (800-1250N)

• 200 mm Open Length / 50 mm Stroke (1000-1250N)

• 300 mm Open Length / 90 mm Stroke (1000-1250N)

• 350 mm Open Length / 110 mm Stroke (1000-1250N)

• 400 mm Open Length / 150 mm Stroke (1000-1250N)

• 500 mm Open Length / 210 mm Stroke (1000-1250N)

• 600 mm Open Length / 250 mm Stroke (1000-1250N)

• 700 mm Open Length / 300 mm Stroke (1000-1250N)

• 750 mm Open Length / 325 mm Stroke (1000-1250N)

• 800 mm Open Length / 350 mm Stroke (1000-1250N)

• 850 mm Open Length / 375 mm Stroke (1000-1250N)

• 900 mm Open Length / 400 mm Stroke (1000-1250N)

• 950 mm Open Length / 425 mm Stroke (1000-1250N)

• 1000 mm Open Length / 445 mm Stroke (1000-1250N)

Ø27 mm Cap:

• 200 mm Open Length / 40 mm Stroke (1500-2000N)

• 300 mm Open Length / 90 mm Stroke (1500-2000N)

• 400 mm Open Length / 140 mm Stroke (1500-2000N)

• 500 mm Open Length / 195 mm Stroke (1500-2000N)

• 600 mm Open Length / 245 mm Stroke (1500-2000N)

• 700 mm Open Length / 295 mm Stroke (1500-2000N)

• 800 mm Open Length / 345 mm Stroke (1500-2000N)

• 900 mm Open Length / 395 mm Stroke (1500-2000N)

• 1000 mm Open Length / 445 mm Stroke (1500-2000N)

Important Information:

• Individual Sale: Each gas strut is sold separately. For pairs, order two units.

• Force Selection: Ensure compatibility by selecting the appropriate force rating based on your load requirements.

• Installation Tips: All gas struts are shipped fully extended due to internal gas pressure. Plan installation accordingly.

• Compatibility Check: Verify dimensions, open length, and hole size to match your system setup.
